TLC339IPW
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tube TLC339 CMOS Open-Drain LinCMOS? comparator circuit 5pA 2500ns 5mm 5mV
PDF
/
Buying Options
Total Price: USD $1.78
Unit Price: USD $1.781641
≥1 USD $1.781641
≥100 USD $1.444636
≥250 USD $1.028119
≥1000 USD $0.762778
Inventory: 10891
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Number of Pins 14
Weight 57.209338mg
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series LinCMOS?
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Type General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Comparator
Max Power Dissipation 700mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Base Part Number TLC339
Pin Count 14
Output Type CMOS, Open-Drain
Operating Supply Voltage 5V
Number of Elements 4
Power Supplies 5V
Nominal Supply Current 20μA
Power Dissipation 700mW
Output Current 20mA
Max Supply Current 20μA
Propagation Delay 4.5 μs
Quiescent Current 125μA
Response Time 2500 ns
Common Mode Rejection Ratio 84 dB
Voltage - Supply, Single/Dual (±) 3V~16V
Output Current per Channel 6mA
Input Offset Voltage (Vos) 5mV
Average Bias Current-Max (IIB) 0.000002μA
Power Supply Rejection Ratio (PSRR) 84dB
Supply Voltage Limit-Max 18V
Max Input Current 5pA
Input Bias Current 5pA
Current - Quiescent (Max) 125μA
Voltage - Input Offset (Max) 5mV @ 10V
Current - Input Bias (Max) 5pA @ 5V
CMRR, PSRR (Typ) 84dB CMRR
Dimensions
Height 1.2mm
Length 5mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
