TL712CDG4
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tube TL712 Complementary Push-Pull Tri-State TTL Nickel/Palladium/Gold (Ni/Pd/Au) comparator circuit 600muA 25ns 4.9mm 5mV
PDF
/
Buying Options
Total Price: USD $1.67
Unit Price: USD $1.665326
≥1 USD $1.665326
≥10 USD $1.571071
≥100 USD $1.482144
≥500 USD $1.398254
≥1000 USD $1.3191
Inventory: 7991
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Weight 72.603129mg
Technical
Operating Temperature 0°C~70°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Differential
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Comparator
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Base Part Number TL712
Pin Count 8
Output Type Complementary, Push-Pull, Tri-State, TTL
Operating Supply Voltage 5V
Number of Elements 1
Power Supplies 5V
Nominal Supply Current 20mA
Max Supply Current 20mA
Propagation Delay 25 ns
Quiescent Current 20mA
Response Time 25 ns
Voltage - Supply, Single/Dual (±) 4.75V~5.25V
Input Offset Voltage (Vos) 5mV
Supply Voltage Limit-Max 7V
Input Bias Current 600μA
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
