TL331IDBVR
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Cut Tape (CT) TL331 CMOS MOS Open-Collector TTL Nickel/Palladium/Gold (Ni/Pd/Au) comparator circuit 250nA 1.3mus 2.9mm 9V
PDF
/
Buying Options
Total Price: USD $0.13
Unit Price: USD $0.1349
≥1 USD $0.1349
≥10 USD $0.1102
≥100 USD $0.10735
≥500 USD $0.10355
≥1000 USD $0.1007
Inventory: 149595
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5
Weight 15.790684mg
Technical
Operating Temperature -40°C~85°C
Packaging Cut Tape (CT)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Termination SMD/SMT
ECCN Code EAR99
Type Differential
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Comparator
Packing Method TR
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Base Part Number TL331
Pin Count 5
Output Type CMOS, MOS, Open-Collector, TTL
Operating Supply Voltage 28V
Number of Circuits 1
Nominal Supply Current 400μA
Output Current 20mA
Max Supply Current 700μA
Quiescent Current 700μA
Response Time 1.3 μs
Voltage - Supply, Single/Dual (±) 2V~36V ±1V~18V
Output Current per Channel 6mA
Input Offset Voltage (Vos) 2V
Voltage Gain 106.02dB
Supply Voltage Limit-Max 36V
Max Input Current 250nA
Dual Supply Voltage 9V
Input Bias Current -25nA
Max Junction Temperature (Tj) 125°C
Voltage - Input Offset (Max) 5mV @ 30V
Current - Input Bias (Max) 0.25μA @ 5V
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
