TL3016IPWR
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
ROHS3Compliant GULL WING BIPOLAR Lead Free with Latch Comparator -40C~85C 525mW 97dB 5V
PDF
/
Buying Options
Total Price: USD $5.09
Unit Price: USD $5.0864
≥1 USD $5.0864
≥10 USD $4.56456
≥100 USD $4.31552
≥500 USD $3.740176
≥1000 USD $3.548371
≥3000 USD $3.183928
Inventory: 1225
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Number of Pins 8
Weight 39.008944mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type with Latch
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Comparator
Packing Method TR
Max Power Dissipation 525mW
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Base Part Number TL3016
Pin Count 8
Output Type Complementary, Push-Pull, TTL
Number of Elements 1
Nominal Supply Current 12.5mA
Power Dissipation 525mW
Output Current 20mA
Max Supply Current 12.5mA
Propagation Delay 10 ns
Quiescent Current 12.5mA
Response Time 7800 ns
Common Mode Rejection Ratio 97 dB
Voltage - Supply, Single/Dual (±) 5V~10V ±2.5V~5V
Input Offset Voltage (Vos) 3mV
Neg Supply Voltage-Nom (Vsup) -5V
Power Supply Rejection Ratio (PSRR) 97dB
Supply Voltage Limit-Max 7V
Max Input Current 10μA
Dual Supply Voltage 5V
Input Bias Current 10μA
Neg Supply Voltage-Max (Vsup) -7V
Voltage - Input Offset (Max) 3mV @ ±5V
Current - Input Bias (Max) 10μA @ ±5V
CMRR, PSRR (Typ) 97dB CMRR
Dimensions
Height 1.2mm
Length 3mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
