LP2901DR
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) LP2901 CMOS MOS Open-Collector e4 comparator circuit 25nA 8mus 8.65mm 5mV
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5456
≥1 USD $0.5456
≥10 USD $0.47784
≥100 USD $0.449152
≥500 USD $0.36652
≥1000 USD $0.340454
≥3000 USD $0.289749
Inventory: 1991
Minimum: 1
-
+
Technical Details
Technical
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Type General Purpose
Subcategory Comparator
Packing Method TR
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Terminal Pitch 1.27mm
Base Part Number LP2901
Pin Count 14
Output Type CMOS, MOS, Open-Collector
Operating Supply Voltage 28V
Number of Elements 4
Power Supplies 5V
Number of Channels 4
Nominal Supply Current 100μA
Power Dissipation 533mW
Output Current 30mA
Max Supply Current 25μA
Quiescent Current 100μA
Response Time 8 μs
Voltage - Supply, Single/Dual (±) 3V~30V
Output Current per Channel 20mA
Input Offset Voltage (Vos) 5mV
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Current - Output (Typ) 30mA @ 5V
Current - Input Bias (Max) 0.025μA @ 5V
Voltage - Input Offset (Max) 5mV @ 30V
Input Bias Current 25nA
Max Input Current 25nA
Supply Voltage Limit-Max 36V
Voltage Gain 113.98dB
Physical
Weight 122.413241mg
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 8.65mm
Height 1.75mm
