LMV7271MG/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 5-TSSOP, SC-70-5, SOT-353
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) LMV7271 CMOS Push-Pull Rail-to-Rail e3 comparator circuit 10nA 1800ns 2mm 4mV
PDF
/
Buying Options
Total Price: USD $1.03
Unit Price: USD $1.0296
≥1 USD $1.0296
≥10 USD $0.92224
≥100 USD $0.870144
≥500 USD $0.741312
≥1000 USD $0.696045
≥3000 USD $0.612691
Inventory: 1667
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 5-TSSOP, SC-70-5, SOT-353
Number of Pins 5
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type General Purpose
Subcategory Comparator
Packing Method TR
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.8V
Base Part Number LMV7271
Pin Count 5
Output Type CMOS, Push-Pull, Rail-to-Rail
Operating Supply Voltage 5V
Number of Elements 1
Nominal Supply Current 14μA
Output Current 34mA
Max Supply Current 9μA
Propagation Delay 2.1 μs
Quiescent Current 10μA
Response Time 1800 ns
Common Mode Rejection Ratio 78 dB
Voltage - Supply, Single/Dual (±) 1.8V~5.5V ±0.9V~2.75V
Input Offset Voltage (Vos) 4mV
Power Supply Rejection Ratio (PSRR) 80dB
Max Input Current 10nA
Input Bias Current 10nA
Voltage - Input Offset (Max) 4mV @ 5V
Current - Input Bias (Max) 0.01μA @ 5V
CMRR, PSRR (Typ) 78dB CMRR, 80dB PSRR
Dimensions
Height 1.1mm
Length 2mm
Width 1.25mm
Thickness 900μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
