LMC6772AIMX
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Non-RoHS Compliant GULL WING CMOS Contains Lead General Purpose Comparator -40C~85C 80dB 5mV 4.9mm
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8303
≥1 USD $0.8303
≥10 USD $0.68115
≥100 USD $0.66025
≥500 USD $0.6384
≥1000 USD $0.6175
Inventory: 3302
Minimum: 1
-
+
Technical Details
Dimensions
Length 4.9mm
Width 3.9mm
Height Seated (Max) 1.75mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Technical
CMRR, PSRR (Typ) 75dB CMRR, 80dB PSRR
Current - Input Bias (Max) 0.04pA @ 5V
Voltage - Input Offset (Max) 5mV @ 5V
Input Bias Current 40 fA
Max Input Current 40 fA
Supply Voltage Limit-Max 16V
Power Supply Rejection Ratio (PSRR) 80dB
Voltage Gain 100dB
Input Offset Voltage (Vos) 5mV
Voltage - Supply, Single/Dual (±) 2.7V~15V ±1.35V~7.5V
Common Mode Rejection Ratio 75 dB
Response Time 4000 ns
Quiescent Current 20μA
Propagation Delay 10 μs
Max Supply Current 20μA
Output Current 30mA
Nominal Supply Current 20μA
Number of Elements 2
Output Type Open Drain
Pin Count 8
Base Part Number LMC6772
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Comparator
Terminal Finish Tin/Lead (Sn/Pb)
Type General Purpose
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
