LM397MF
RoHS
/
Package SC-74A, SOT-753
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) LM397 CMOS Open-Collector TTL Tin/Lead (Sn/Pb) comparator circuit 250nA 940000ns 2.9mm 7mV
PDF
/
Buying Options
Total Price: USD $1.59
Unit Price: USD $1.5928
≥1 USD $1.5928
≥10 USD $1.43
≥100 USD $1.348864
≥500 USD $1.149104
≥1000 USD $1.079021
≥3000 USD $0.944134
Inventory: 2065
Minimum: 1
-
+
Technical Details
Technical
JESD-609 Code e0
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type General Purpose
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Comparator
Packing Method TR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Base Part Number LM397
Pin Count 5
Output Type CMOS, Open-Collector, TTL
Operating Supply Voltage 30V
Number of Circuits 1
Nominal Supply Current 700μA
Output Current 13mA
Max Supply Current 700μA
Propagation Delay 940 μs
Quiescent Current 2mA
Response Time 940000 ns
Voltage - Supply, Single/Dual (±) 5V~30V ±2.5V~15V
Input Offset Voltage (Vos) 7mV
Voltage Gain 101.6dB
Max Input Current 250nA
Input Bias Current 250nA
Current - Quiescent (Max) 2mA
Voltage - Input Offset (Max) 7mV @ 30V
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Current - Input Bias (Max) 0.25μA @ 5V
Current - Output (Typ) 13mA @ 5V
Physical
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Alternative Model
