LM393ADGKRG4
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) LM393 CMOS MOS Open-Drain TTL 0.05muA comparator circuit 0.25muA @ 5V 300ns 3mm 2mV
PDF
/
Buying Options
Total Price: USD $0.13
Unit Price: USD $0.130874
≥1 USD $0.130874
≥10 USD $0.122434
≥100 USD $0.113986
≥500 USD $0.108082
≥1000 USD $0.105547
Inventory: 1525
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 970μm
Width 3mm
Length 3mm
Height 1.07mm
Technical
Current - Input Bias (Max) 0.25μA @ 5V
Voltage - Input Offset (Max) 2mV @ 30V
Input Bias Current 250nA
Supply Voltage Limit-Max 36V
Average Bias Current-Max (IIB) 0.05μA
Voltage Gain 106.02dB
Input Offset Voltage (Vos) 2mV
Output Current per Channel 6mA
Voltage - Supply, Single/Dual (±) 2V~36V ±1V~18V
Response Time 300 ns
Quiescent Current 2.5mA
Max Supply Current 500μA
Output Current 20mA
Nominal Supply Current 500μA
Power Supplies 5V
Number of Elements 2
Output Type CMOS, MOS, Open-Drain, TTL
Pin Count 8
Base Part Number LM393
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TR
Subcategory Comparator
Type Differential
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Weight 18.99418mg
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 8 Weeks
