LM161H/883
RoHS
/
Package TO-100
Category Integrated Circuits (ICs) / Linear - Comparators
Description
COMPARATOR RoHS Compliant WIRE MILITARY comparator circuit 125C 600mW 69.54dB 3mV
PDF
/
Buying Options
Total Price: USD $117.56
Unit Price: USD $117.5592
≥1 USD $117.5592
Inventory: 178
Minimum: 1
-
+
Technical Details
Technical
Amplifier Type COMPARATOR
Current - Input Bias 20μA
Input Offset Voltage (Vos) 3mV
Neg Supply Voltage-Nom (Vsup) -10V
Voltage Gain 69.54dB
Screening Level MIL-STD-883
Response Time 20 ns
Power Dissipation 600mW
Nominal Supply Current 18mA
Temperature Grade MILITARY
Number of Elements 1
Output Type OPEN-COLLECTOR
Supply Voltage 10V
Number of Functions 1
Terminal Form WIRE
Terminal Position BOTTOM
Technology BIPOLAR
Subcategory Comparator
Min Operating Temperature -55°C
Max Operating Temperature 125°C
ECCN Code EAR99
Number of Terminations 10
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
Physical
Number of Pins 10
Package / Case TO-100
Mount Through Hole
