LM111J-8
RoHS
/
Package 8-CDIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tube LM111 DTL MOS Open-Collector Open-Emitter RTL TTL Tin/Lead (Sn/Pb) comparator circuit 100nA 200ns 10.16mm 3mV
PDF
/
Buying Options
Total Price: USD $15.1
Unit Price: USD $15.1008
≥1 USD $15.1008
≥10 USD $13.87936
≥100 USD $13.30384
≥500 USD $11.72182
≥1000 USD $11.146485
≥3000 USD $10.427358
Inventory: 447
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 4.064mm
Width 6.502mm
Length 10.16mm
Height 5.08mm
Technical
Current - Input Bias (Max) 0.1μA @ ±15V
Voltage - Input Offset (Max) 3mV @ ±15V
Input Bias Current 60nA
Max Input Current 100nA
Voltage Gain 106.02dB
Neg Supply Voltage-Nom (Vsup) -15V
Input Offset Voltage (Vos) 3mV
Voltage - Supply, Single/Dual (±) 5V~36V ±2.5V~18V
Response Time 200 ns
Quiescent Current 5.1mA
Max Supply Current 6mA
Output Current 50mA
Power Dissipation 500mW
Nominal Supply Current 5.1mA
Number of Circuits 1
Output Type DTL, MOS, Open-Collector, Open-Emitter, RTL, TTL
Pin Count 8
Base Part Number LM111
Terminal Pitch 2.54mm
Supply Voltage 15V
Number of Functions 1
Terminal Position DUAL
Technology BIPOLAR
Max Power Dissipation 500mW
Subcategory Comparator
Terminal Finish Tin/Lead (Sn/Pb)
Type General Purpose
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Weight 4.535924g
Number of Pins 8
Package / Case 8-CDIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Lead, Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 26 Weeks
