TS862ID
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tube TS862 Push-Pull 0.0006muA comparator circuit 300pA @ 5V 2000ns 4.9mm 15mV
PDF
/
Buying Options
Total Price: USD $2.49
Unit Price: USD $2.489
≥1 USD $2.489
≥10 USD $2.0425
≥100 USD $1.97885
≥500 USD $1.91425
≥1000 USD $1.8506
Inventory: 1733
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
CMRR, PSRR (Typ) 70dB CMRR
Current - Input Bias (Max) 300pA @ 5V
Voltage - Input Offset (Max) 15mV @ 5V
Current - Quiescent (Max) 16μA
Input Bias Current 300pA
Power Supply Rejection Ratio (PSRR) 80dB
Average Bias Current-Max (IIB) 0.0006μA
Voltage Gain 240dB
Input Offset Voltage (Vos) 15mV
Voltage - Supply, Single/Dual (±) 2.7V~10V
Common Mode Rejection Ratio 70 dB
Response Time 2000 ns
Quiescent Current 16μA
Propagation Delay 2 μs
Max Supply Current 28μA
Power Dissipation 710mW
Nominal Supply Current 28μA
Number of Elements 2
Output Type Push-Pull
Pin Count 8
Base Part Number TS862
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Max Power Dissipation 710mW
Subcategory Comparator
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
