TS861IN
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tube TS861 Push-Pull 0.0006muA comparator circuit 300pA 2000ns 2.54mm 15mV
PDF
/
Inventory: 7913
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.62mm
Technical
CMRR, PSRR (Typ) 70dB CMRR
Current - Input Bias (Max) 300pA @ 5V
Voltage - Input Offset (Max) 15mV @ 5V
Current - Quiescent (Max) 16μA
Input Bias Current 600pA
Max Input Current 300pA
Average Bias Current-Max (IIB) 0.0006μA
Voltage Gain 240dB
Input Offset Voltage (Vos) 15mV
Output Current per Channel 5mA
Voltage - Supply, Single/Dual (±) 2.7V~10V
Common Mode Rejection Ratio 70 dB
Response Time 2000 ns
Quiescent Current 16μA
Propagation Delay 2 μs
Max Supply Current 12μA
Output Current 5mA
Nominal Supply Current 12μA
Number of Elements 1
Output Type Push-Pull
Pin Count 8
Base Part Number TS861
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Technology BICMOS
Max Power Dissipation 1.25W
Subcategory Comparator
Terminal Finish Matte Tin (Sn)
Type General Purpose
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
