TS3704CN
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tube TS3704 CMOS Push-Pull 0.0006muA comparator circuit 1pA 1.2mus 20mm 5mV
PDF
/
Inventory: 7887
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Length 20mm
Height Seated (Max) 5.1mm
Technical
CMRR, PSRR (Typ) 80dB CMRR
Current - Input Bias (Max) 1pA @ 5V
Voltage - Input Offset (Max) 5mV @ 10V
Input Bias Current 600pA
Max Input Current 1pA
Supply Voltage Limit-Max 18V
Power Supply Rejection Ratio (PSRR) 92dB
Average Bias Current-Max (IIB) 0.0006μA
Input Offset Voltage (Vos) 5mV
Output Current per Channel 4mA
Voltage - Supply, Single/Dual (±) 2.7V~16V ±1.35V~8V
Common Mode Rejection Ratio 80 dB
Response Time 1.2 μs
Quiescent Current 25μA
Max Supply Current 25μA
Output Current 20mA
Power Dissipation 1.5W
Nominal Supply Current 25μA
Power Supplies 5V
Number of Elements 4
Output Type CMOS, Push-Pull
Qualification Status Not Qualified
Pin Count 14
Base Part Number TS3704
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 3V
Number of Functions 4
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Max Power Dissipation 1.5W
Subcategory Comparator
Terminal Finish Matte Tin (Sn)
Type General Purpose
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
