TS3702ID
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tube TS3702 CMOS Push-Pull 0.0006muA comparator circuit 1pA 1.5mus 4.9mm 5mV
PDF
/
Buying Options
Total Price: USD $0.44
Unit Price: USD $0.4427
≥1 USD $0.4427
≥10 USD $0.36385
≥100 USD $0.35245
≥500 USD $0.34105
≥1000 USD $0.32965
Inventory: 57238
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Natural Thermal Resistance 175 °C/W
CMRR, PSRR (Typ) 82dB CMRR
Current - Input Bias (Max) 1pA @ 5V
Voltage - Input Offset (Max) 5mV @ 10V
Input Bias Current 600pA
Max Input Current 1pA
Power Supply Rejection Ratio (PSRR) 90dB
Average Bias Current-Max (IIB) 0.0006μA
Input Offset Voltage (Vos) 5mV
Output Current per Channel 4mA
Voltage - Supply, Single/Dual (±) 2.7V~16V ±1.35V~8V
Common Mode Rejection Ratio 82 dB
Response Time 1.5 μs
Quiescent Current 25μA
Max Supply Current 20μA
Output Current 20mA
Power Dissipation 710mW
Nominal Supply Current 40μA
Number of Elements 2
Output Type CMOS, Push-Pull
Pin Count 8
Base Part Number TS3702
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 3V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 710mW
Subcategory Comparator
Type General Purpose
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
