TS339ID
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tube TS339 CMOS Open-Drain 0.0006muA comparator circuit 1pA 1.5mus 8.65mm 5mV
PDF
/
Buying Options
Total Price: USD $0.91
Unit Price: USD $0.91295
≥1 USD $0.91295
≥10 USD $0.74955
≥100 USD $0.7258
≥500 USD $0.70205
≥1000 USD $0.67925
Inventory: 6003
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
CMRR, PSRR (Typ) 75dB CMRR
Current - Input Bias (Max) 1pA @ 5V
Voltage - Input Offset (Max) 5mV @ 10V
Input Bias Current 600pA
Max Input Current 1pA
Supply Voltage Limit-Max 18V
Power Supply Rejection Ratio (PSRR) 85dB
Average Bias Current-Max (IIB) 0.0006μA
Input Offset Voltage (Vos) 5mV
Output Current per Channel 2nA
Voltage - Supply, Single/Dual (±) 2.7V~16V ±1.35V~8V
Common Mode Rejection Ratio 75 dB
Response Time 1.5 μs
Quiescent Current 25μA
Max Supply Current 20μA
Output Current 20mA
Power Dissipation 830mW
Nominal Supply Current 80μA
Power Supplies 5V
Number of Elements 4
Output Type CMOS, Open-Drain
Pin Count 14
Base Part Number TS339
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 3V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 830mW
Subcategory Comparator
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
