LMV339IPT
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
ROHS3Compliant Lead Free General Purpose Surface Mount comparator circuit 100C/W 85C 93.98dB 7mV
PDF
/
Buying Options
Total Price: USD $1.01
Unit Price: USD $1.012
≥1 USD $1.012
≥10 USD $0.902
≥100 USD $0.855712
≥500 USD $0.703032
≥1000 USD $0.657149
≥3000 USD $0.580747
Inventory: 1511
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Propagation Delay (Max) 375ns
Current - Output (Typ) 93mA @ 5V
Natural Thermal Resistance 100 °C/W
Current - Input Bias (Max) 0.25μA @ 5V
Voltage - Input Offset (Max) 7mV @ 5V
Current - Quiescent (Max) 120μA
Input Bias Current 250nA
Max Input Current 250nA
Voltage Gain 93.98dB
Input Offset Voltage (Vos) 7mV
Voltage - Supply, Single/Dual (±) 2.7V~5V
Quiescent Current 120μA
Propagation Delay 375 ns
Output Current 93mA
Operating Supply Current 150μA
Min Supply Voltage 2.7V
Max Supply Voltage 5V
Number of Channels 4
Number of Elements 4
Operating Supply Voltage 3V
Output Type Open Drain
Base Part Number LMV339
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type General Purpose
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 140.30179mg
Supplier Device Package 14-TSSOP
Number of Pins 14
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 12 Weeks
