LM393ST
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
ROHS3Compliant GULL WING BIPOLAR Lead Free General Purpose Comparator 190C/W 0C~70C 580mW 106.02dB
PDF
/
Buying Options
Total Price: USD $0.64
Unit Price: USD $0.6424
≥1 USD $0.6424
≥10 USD $0.56232
≥100 USD $0.528
≥500 USD $0.430848
≥1000 USD $0.400189
≥3000 USD $0.340595
Inventory: 14465
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Number of Pins 8
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type General Purpose
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Comparator
Max Power Dissipation 580mW
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LM393
Pin Count 8
Output Type CMOS, DTL, ECL, MOS, Open-Collector, TTL
Number of Elements 2
Nominal Supply Current 1mA
Power Dissipation 580mW
Output Current 18mA
Max Supply Current 1mA
Quiescent Current 2.5mA
Response Time 1.3 μs
Voltage - Supply, Single/Dual (±) 2V~36V ±1V~18V
Input Offset Voltage (Vos) 5mV
Voltage Gain 106.02dB
Average Bias Current-Max (IIB) 0.4μA
Supply Voltage Limit-Max 36V
Max Input Current 250nA
Input Bias Current 250nA
Voltage - Input Offset (Max) 5mV @ 30V
Current - Input Bias (Max) 0.25μA @ 5V
Natural Thermal Resistance 190 °C/W
Current - Output (Typ) 18mA @ 5V
Dimensions
Height 950μm
Length 3.2mm
Width 3.1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
