LM293PT
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) LM293 CMOS DTL ECL MOS Open-Collector TTL 0.4muA comparator circuit 250nA 1.3mus 4.4mm 5mV
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5544
≥1 USD $0.5544
≥10 USD $0.484
≥100 USD $0.455136
≥500 USD $0.37136
≥1000 USD $0.34496
≥3000 USD $0.293586
Inventory: 112723
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type General Purpose
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Comparator
Max Power Dissipation 625mW
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LM293
Pin Count 8
Output Type CMOS, DTL, ECL, MOS, Open-Collector, TTL
Number of Elements 2
Nominal Supply Current 1mA
Power Dissipation 625mW
Output Current 18mA
Max Supply Current 1mA
Quiescent Current 2.5mA
Response Time 1.3 μs
Voltage - Supply, Single/Dual (±) 2V~36V ±1V~18V
Output Current per Channel 100pA
Input Offset Voltage (Vos) 5mV
Voltage Gain 106.02dB
Average Bias Current-Max (IIB) 0.4μA
Supply Voltage Limit-Max 36V
Max Input Current 250nA
Input Bias Current 250nA
Voltage - Input Offset (Max) 5mV @ 30V
Current - Input Bias (Max) 0.25μA @ 5V
Natural Thermal Resistance 85 °C/W
Current - Output (Typ) 18mA @ 5V
Dimensions
Length 4.4mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
