NCS2200SN1T1
RoHS
/
Package SOT-23-5 Thin, TSOT-23-5
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) NCS220* Complementary Rail-to-Rail NCS2200 comparator circuit 1pA 1100ns 3mm 20mV
PDF
/
Buying Options
Total Price: USD $0.5
Unit Price: USD $0.4978
≥1 USD $0.4978
≥10 USD $0.4085
≥100 USD $0.39615
≥500 USD $0.38285
≥1000 USD $0.3705
Inventory: 1368
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Length 3mm
Technical
CMRR, PSRR (Typ) 70dB CMRR, 80dB PSRR
Hysteresis 20mV
Current - Input Bias (Max) 1pA @ 6V
Voltage - Input Offset (Max) 5mV @ 6V
Current - Quiescent (Max) 17μA
Input Bias Current 1pA
Max Input Current 1pA
Supply Voltage Limit-Max 6V
Power Supply Rejection Ratio (PSRR) 80dB
Input Offset Voltage (Vos) 5mV
Output Current per Channel 70mA
Voltage - Supply, Single/Dual (±) 0.85V~6V
Common Mode Rejection Ratio 80 dB
Response Time 1100 ns
Quiescent Current 17μA
Propagation Delay 1.1 μs
Max Supply Current 15μA
Output Current 70mA
Nominal Supply Current 15μA
Number of Elements 1
Output Type Complementary, Rail-to-Rail
Qualification Status Not Qualified
Pin Count 5
Base Part Number NCS220*
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Comparators
Terminal Finish Tin/Lead (Sn/Pb)
Type General Purpose
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Series NCS2200
Published 2003
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Number of Pins 5
Package / Case SOT-23-5 Thin, TSOT-23-5
Mounting Type Surface Mount
Mount Surface Mount
