MIC6270YM5-TR
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) MIC6270 CMOS DTL ECL MOS Open-Collector TTL IttyBitty? comparator circuit 250nA 600ns 2.9mm 15V
PDF
/
Buying Options
Total Price: USD $0.44
Unit Price: USD $0.43579
≥1 USD $0.43579
≥10 USD $0.41113
≥100 USD $0.38786
≥500 USD $0.3659
≥1000 USD $0.34519
Inventory: 3000
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 1.6mm
Length 2.9mm
Height 1.1mm
Technical
Current - Output (Typ) 20mA @ 5V
Natural Thermal Resistance 220 °C/W
Current - Input Bias (Max) 0.25μA @ 5V
Voltage - Input Offset (Max) 5mV @ 5V
Current - Quiescent (Max) 1.2mA
Input Bias Current 250nA
Dual Supply Voltage 15V
Max Input Current 250nA
Min Dual Supply Voltage 1V
Max Dual Supply Voltage 18V
Voltage Gain 106.02dB
Input Offset Voltage (Vos) 5mV
Output Current per Channel 400μA
Voltage - Supply, Single/Dual (±) 2V~36V ±1V~18V
Response Time 600 ns
Quiescent Current 1.2mA
Max Supply Current 1.2mA
Output Current 20mA
Nominal Supply Current 900μA
Min Supply Voltage 2V
Max Supply Voltage 36V
Number of Channels 1
Number of Elements 1
Output Type CMOS, DTL, ECL, MOS, Open-Collector, TTL
Base Part Number MIC6270
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type General Purpose
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series IttyBitty?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Supplier Device Package SOT-23-5
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
