MCP6569T-E/SL
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) MCP6569 CMOS Open-Drain Matte Tin (Sn) - annealed comparator circuit 1pA @ 5.5V 56ns 8.65mm 5mV
PDF
/
Inventory: 4836
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Type General Purpose
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Comparator
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 1.8V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP6569
Pin Count 14
Output Type CMOS, Open-Drain
Number of Elements 4
Power Supplies 2/5V
Output Current 50mA
Propagation Delay 80 ns
Quiescent Current 130μA
Supply Current-Max 0.13mA
Response Time 56 ns
Common Mode Rejection Ratio 66 dB
Voltage - Supply, Single/Dual (±) 1.8V~5.5V
Input Offset Voltage (Vos) 10mV
Power Supply Rejection Ratio (PSRR) 70dB
Supply Voltage Limit-Max 6.5V
Input Bias Current 1pA
Current - Quiescent (Max) 130μA
Voltage - Input Offset (Max) 10mV @ 5.5V
Current - Input Bias (Max) 1pA @ 5.5V
Hysteresis 5mV
CMRR, PSRR (Typ) 66dB CMRR, 70dB PSRR
Dimensions
Height Seated (Max) 1.75mm
Length 8.65mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
