MCP6549T-E/ST
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) MCP6549 CMOS Open-Drain Rail-to-Rail TTL 0.005muA comparator circuit 1pA @ 5.5V 3000ns 5mm 6.5mV
PDF
/
Buying Options
Total Price: USD $1.15
Unit Price: USD $1.1528
≥1 USD $1.1528
≥10 USD $0.9592
≥100 USD $0.8712
Inventory: 1720
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Number of Pins 14
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2007
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Type General Purpose
Terminal Finish Matte Tin (Sn)
Subcategory Comparator
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP6549
Pin Count 14
Output Type CMOS, Open-Drain, Rail-to-Rail, TTL
Number of Elements 4
Power Supplies 1.6/5.5V
Output Current 30mA
Propagation Delay 8 μs
Quiescent Current 1μA
Supply Current-Max 0.001mA
Response Time 3000 ns
Common Mode Rejection Ratio 70 dB
Voltage - Supply, Single/Dual (±) 1.6V~5.5V
Input Offset Voltage (Vos) 7mV
Average Bias Current-Max (IIB) 0.005μA
Power Supply Rejection Ratio (PSRR) 80dB
Supply Voltage Limit-Max 7V
Input Bias Current 1pA
Current - Quiescent (Max) 1μA
Voltage - Input Offset (Max) 7mV @ 5.5V
Current - Input Bias (Max) 1pA @ 5.5V
Hysteresis 6.5mV
CMRR, PSRR (Typ) 70dB CMRR, 80dB PSRR
Natural Thermal Resistance 100 °C/W
Dimensions
Height Seated (Max) 1.2mm
Length 5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
