MCP6543T-I/MS
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) MCP6543 CMOS Push-Pull Rail-to-Rail TTL Matte Tin (Sn) comparator circuit 1pA 4000ns 3mm 6.5mV
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.05505
≥1 USD $8.05505
≥10 USD $6.60915
≥100 USD $6.403
≥500 USD $6.1959
≥1000 USD $5.98975
Inventory: 1252
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Technical
CMRR, PSRR (Typ) 70dB CMRR, 80dB PSRR
Hysteresis 6.5mV
Current - Input Bias (Max) 1pA @ 5.5V
Voltage - Input Offset (Max) 7mV @ 5.5V
Current - Quiescent (Max) 1μA
Input Bias Current 1pA
Max Input Current 1pA
Supply Voltage Limit-Max 7V
Power Supply Rejection Ratio (PSRR) 80dB
Input Offset Voltage (Vos) 7mV
Output Current per Channel 2mA
Voltage - Supply, Single/Dual (±) 1.6V~5.5V
Common Mode Rejection Ratio 70 dB
Response Time 4000 ns
Quiescent Current 1μA
Propagation Delay 8 μs
Max Supply Current 1mA
Output Current 2mA
Nominal Supply Current 1mA
Number of Elements 1
Output Type CMOS, Push-Pull, Rail-to-Rail, TTL
Pin Count 8
Base Part Number MCP6543
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Comparator
Terminal Finish Matte Tin (Sn)
Type General Purpose
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
Alternative Model
