MCP6543-E/P
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tube MCP6543 CMOS Push-Pull Rail-to-Rail TTL 0.005muA comparator circuit 1pA @ 5.5V 4000ns 10.16mm 6.5mV
PDF
/
Inventory: 2750
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 7.112mm
Length 10.16mm
Height 4.953mm
Technical
CMRR, PSRR (Typ) 70dB CMRR, 80dB PSRR
Hysteresis 6.5mV
Current - Input Bias (Max) 1pA @ 5.5V
Voltage - Input Offset (Max) 7mV @ 5.5V
Current - Quiescent (Max) 1μA
Input Bias Current 1pA
Supply Voltage Limit-Max 7V
Power Supply Rejection Ratio (PSRR) 80dB
Average Bias Current-Max (IIB) 0.005μA
Input Offset Voltage (Vos) 7mV
Voltage - Supply, Single/Dual (±) 1.6V~5.5V
Common Mode Rejection Ratio 70 dB
Response Time 4000 ns
Quiescent Current 1μA
Propagation Delay 8 μs
Nominal Supply Current 600nA
Number of Elements 1
Output Type CMOS, Push-Pull, Rail-to-Rail, TTL
Pin Count 8
Base Part Number MCP6543
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Subcategory Comparator
Terminal Finish Matte Tin (Sn)
Type General Purpose
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2006
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
Alternative Model
