MCP6542-E/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tube MCP6542 CMOS Push-Pull Rail-to-Rail TTL 0.005muA comparator circuit 1pA @ 5.5V 4000ns 4.9mm 6.5mV
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5456
≥1 USD $0.5456
≥10 USD $0.4576
≥100 USD $0.4136
Inventory: 3076
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Height 1.25mm
Technical
Natural Thermal Resistance 163 °C/W
CMRR, PSRR (Typ) 70dB CMRR, 80dB PSRR
Hysteresis 6.5mV
Current - Input Bias (Max) 1pA @ 5.5V
Voltage - Input Offset (Max) 7mV @ 5.5V
Current - Quiescent (Max) 1μA
Input Bias Current 1pA
Supply Voltage Limit-Max 7V
Power Supply Rejection Ratio (PSRR) 80dB
Average Bias Current-Max (IIB) 0.005μA
Input Offset Voltage (Vos) 7mV
Voltage - Supply, Single/Dual (±) 1.6V~5.5V
Common Mode Rejection Ratio 70 dB
Response Time 4000 ns
Supply Current-Max 0.001mA
Quiescent Current 1μA
Propagation Delay 8 μs
Power Supplies 1.6/5.5V
Number of Elements 2
Output Type CMOS, Push-Pull, Rail-to-Rail, TTL
Pin Count 8
Base Part Number MCP6542
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Comparator
Terminal Finish Matte Tin (Sn)
Type General Purpose
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2005
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
Alternative Model
