MAX987EUK+TG103
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) MAX987 CMOS Push-Pull Rail-to-Rail TTL Matte Tin (Sn) comparator circuit 1pA @ 5.5V 210ns 2.9mm ±2.5mV
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.224181
≥1 USD $3.224181
≥10 USD $3.04168
≥100 USD $2.869504
≥500 USD $2.707084
≥1000 USD $2.553848
Inventory: 1534
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2007
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type General Purpose
Terminal Finish Matte Tin (Sn)
Subcategory Comparator
Max Power Dissipation 471mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.7V
Base Part Number MAX987
Pin Count 5
Output Type CMOS, Push-Pull, Rail-to-Rail, TTL
Number of Elements 1
Nominal Supply Current 80μA
Max Supply Current 80μA
Propagation Delay 210 ns
Quiescent Current 96μA
Response Time 210 ns
Common Mode Rejection Ratio 80 dB
Voltage - Supply, Single/Dual (±) 2.5V~5.5V ±1.25V~2.75V
Input Offset Voltage (Vos) 5mV
Power Supply Rejection Ratio (PSRR) 80dB
Supply Voltage Limit-Max 6V
Input Bias Current 1pA
Current - Quiescent (Max) 96μA
Voltage - Input Offset (Max) 5mV @ 5.5V
Current - Input Bias (Max) 1pA @ 5.5V
Hysteresis ±2.5mV
CMRR, PSRR (Typ) 80dB CMRR, 80dB PSRR
Dimensions
Length 2.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
