LT1720CMS8#PBF
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tube LT1720 CMOS Rail-to-Rail TTL UltraFast? comparator circuit 6muA @ 5V 7ns 3mm 7mV
PDF
/
Buying Options
Total Price: USD $9.75
Unit Price: USD $9.7504
≥1 USD $9.7504
≥10 USD $8.80968
≥100 USD $8.3996
≥500 USD $7.293352
≥1000 USD $6.965517
≥3000 USD $6.350925
Inventory: 1197
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2008
Series UltraFast?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type General Purpose
Terminal Finish Matte Tin (Sn)
Subcategory Comparator
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LT1720
Pin Count 8
JESD-30 Code S-PDSO-G8
Qualification Status Not Qualified
Output Type CMOS, Rail-to-Rail, TTL
Number of Elements 2
Power Supplies 5V
Supply Current-Max 7mA
Response Time 7 ns
Voltage - Supply, Single/Dual (±) 2.7V~6V
Average Bias Current-Max (IIB) 6μA
Supply Voltage Limit-Max 7V
Current - Quiescent (Max) 7mA
Voltage - Input Offset (Max) 3mV @ 5V
Current - Input Bias (Max) 6μA @ 5V
Hysteresis 7mV
CMRR, PSRR (Typ) 70dB CMRR, 80dB PSRR
Current - Output (Typ) 20mA
Propagation Delay (Max) 10ns
Dimensions
Height Seated (Max) 1.1mm
Length 3mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
