LT1711CMS8
RoHS
/
Package MSOP
Category Integrated Circuits (ICs) / Linear - Comparators
Description
RoHS Compliant Contains Lead 5muA TTL comparator circuit 85C 85dB 3V 5.5ns
PDF
/
Buying Options
Total Price: USD $8.86
Unit Price: USD $8.8597
≥1 USD $8.8597
≥10 USD $7.27035
≥100 USD $7.04235
≥500 USD $6.8153
≥1000 USD $6.58825
Inventory: 7807
Minimum: 1
-
+
Technical Details
Physical
Package / Case MSOP
Number of Pins 8
Technical
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Output Type TTL
Number of Elements 1
Number of Channels 1
Max Supply Voltage 12V
Min Supply Voltage 2.4V
Current - Output 20mA
Propagation Delay 6 ns
Quiescent Current 22mA
Response Time 5.5 ns
Common Mode Rejection Ratio 85 dB
Current - Input Bias 5μA
Input Offset Voltage (Vos) 5mV
Voltage Gain 83.52dB
Power Supply Rejection Ratio (PSRR) 85dB
Max Dual Supply Voltage 3.5V
Min Dual Supply Voltage 1.2V
Dual Supply Voltage 3V
Hysteresis 100 mV
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
Alternative Model
