THS7347IPHPR
RoHS
RoHS compliant
RoHS compliantPackage 48-PowerTQFP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Video Amps and Modules
Description
THS7347 Tape & Reel (TR) e4 QUAD video amp IC 85C 6dB 1.2mm 80mA
PDF
/
Buying Options
Total Price: USD $4.36
Unit Price: USD $4.356
≥1 USD $4.356
≥10 USD $3.9336
≥100 USD $3.750208
≥500 USD $3.256352
≥1000 USD $3.2208
Inventory: 1019
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1mm
Width 7mm
Length 7mm
Height 1.2mm
Technical
-3db Bandwidth 550MHz
Gain 6 dB
Supply Voltage Limit-Max 5.5V
Supply Type Single
Output Current per Channel 110mA
Voltage - Supply, Single/Dual (±) 2.7V~5.5V
Slew Rate 1200V/μs
Output Current 80mA
Nominal Supply Current 80mA
Operating Supply Current 90mA
Number of Circuits 3
Temperature Grade INDUSTRIAL
Output Type Rail-to-Rail
Pin Count 48
Base Part Number THS7347
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 3
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Packing Method TR
Applications Buffer
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Physical
Weight 134.490138mg
Number of Pins 48
Package / Case 48-PowerTQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
