LM6584MT/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Video Amps and Modules
Description
LM6584 Tube e3 DUAL audio video amplifier circuit 85C 72dB 1.2mm 1muA
PDF
/
Buying Options
Total Price: USD $3.4
Unit Price: USD $3.39658
≥1 USD $3.39658
≥100 USD $2.565336
≥250 USD $1.871561
≥1000 USD $1.31904
Inventory: 1226
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Number of Pins 14
Technical
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications General Purpose
Subcategory Operational Amplifier
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Base Part Number LM6584
Pin Count 14
Output Type Rail-to-Rail
Number of Elements 4
Power Supplies +-2.5/+-6.5/+5/+13V
Temperature Grade INDUSTRIAL
Operating Supply Current 780μA
Nominal Supply Current 1.35mA
Output Current 75mA
Slew Rate 15V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type OPERATIONAL AMPLIFIER
Common Mode Rejection Ratio 72 dB
Voltage - Supply, Single/Dual (±) 5V~13V ±2.5V~6.5V
Output Current per Channel 75mA
Input Offset Voltage (Vos) 6mV
Gain Bandwidth Product 15.3MHz
Unity Gain BW-Nom 15400 kHz
Voltage Gain 106dB
Average Bias Current-Max (IIB) 1μA
Power Supply Rejection Ratio (PSRR) 75dB
Low-Offset NO
Frequency Compensation YES
Low-Bias NO
Micropower NO
-3db Bandwidth 24MHz
Bias Current-Max (IIB) @25C 1μA
Programmable Power NO
Input Bias Current 7μA
Wideband NO
Input Offset Current-Max (IIO) 0.15μA
Dimensions
Height 1.2mm
Length 5mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
