BUF07703PWP
RoHS
RoHS compliant
RoHS compliantPackage 20-PowerTSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Video Amps and Modules
Description
Not Qualified INDUSTRIAL Surface Mount Rail-to-Rail Video Amp 1V/mus 3.83W 800kHz 12mV
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.3414
≥1 USD $1.3414
≥10 USD $1.10105
≥100 USD $1.0659
≥500 USD $1.0317
≥1000 USD $0.9975
Inventory: 1802
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 1.2mm
Technical
Input Bias Current 1pA
-3db Bandwidth 800kHz
Input Offset Voltage (Vos) 12mV
Voltage - Supply, Single/Dual (±) 4.5V~16V
Slew Rate 1V/μs
Output Current 30mA
Nominal Supply Current 2mA
Operating Supply Current 1.7mA
Number of Circuits 6
Temperature Grade INDUSTRIAL
Output Type Rail-to-Rail
Qualification Status Not Qualified
Pin Count 20
Base Part Number BUF07703
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 10V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 3.83W
Subcategory Buffer Amplifier
HTS Code 8542.39.00.01
Applications TFT-LCD Panels: Gamma Buffer, VCOM Driver
Min Operating Temperature 0°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e4
Packaging Tube
Physical
Weight 81.788374mg
Number of Pins 20
Package / Case 20-PowerTSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
