TSM102AID
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Special Purpose
Description
IC OPAMP/COMP/REF DUAL 16SOIC
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.52915
≥1 USD $0.52915
≥10 USD $0.43415
≥100 USD $0.42085
≥500 USD $0.40755
≥1000 USD $0.3933
Inventory: 20001
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 9.9mm
Height Seated (Max) 1.75mm
Technical
Max I/O Voltage 4.5mV
Nominal Gain Bandwidth Product 2.1MHz
Input Bias Current 200nA
Bias Current-Max (IIB) @25C 0.1μA
Supply Voltage Limit-Max 36V
Frequency Compensation YES
Low-Offset NO
Unity Gain BW-Nom 21000 kHz
Gain Bandwidth Product 2.1MHz
Bandwidth 2.1MHz
Input Offset Voltage (Vos) 4.5mV
Common Mode Rejection Ratio 70 dB
Architecture VOLTAGE-FEEDBACK
Slew Rate 2 V/μs
Output Current 6mA
Nominal Supply Current 1.5mA
Number of Channels 2
Temperature Grade INDUSTRIAL
Operating Supply Voltage 30V
Pin Count 16
Base Part Number TSM102
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Operational Amplifier
Applications Power Management
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Amplifier, Comparator, Reference
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Packaging Tube
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
