MAX3761EEP
RoHS
/
Package 20-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Special Purpose
Description
LIMITING AMPLIFIER
PDF
/
Buying Options
Total Price: USD $2.64
Unit Price: USD $2.6353
≥1 USD $2.6353
≥10 USD $2.1622
≥100 USD $2.09475
≥500 USD $2.0273
≥1000 USD $1.95985
Inventory: 1283
Minimum: 1
-
+
Technical Details
Technical
Operating Temperature (Min) -40°C
Temperature Grade INDUSTRIAL
Operating Temperature (Max) 85°C
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G20
Pin Count 20
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.635mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position DUAL
Applications Optical Networks
Terminal Finish TIN LEAD
Type Limiting Amplifier
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Physical
Surface Mount YES
Package / Case 20-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.73mm
