MAX4375TESD+
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Special Purpose
Description
IC AMP CURRENT SENSE 14-SOIC
PDF
/
Buying Options
Total Price: USD $5.35
Unit Price: USD $5.3504
≥1 USD $5.3504
≥10 USD $4.83472
≥100 USD $4.609792
≥500 USD $4.002592
≥1000 USD $3.82272
≥3000 USD $3.485434
Inventory: 111
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Supply Current-Max (Isup) 0.1mA
Bandwidth 200 kHz
Supply Voltage-Min (Vsup) 2.7V
Temperature Grade INDUSTRIAL
Power Supplies 2.7/28V
Supply Voltage-Max (Vsup) 28V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Pin Count 14
Base Part Number MAX4375
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 12V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Power Management Circuits
HTS Code 8542.33.00.01
Applications Current Sensing, Power Management
Terminal Finish Matte Tin (Sn)
Type Amplifier, Comparator, Reference
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2012
Packaging Tube
Physical
Number of Pins 14
Surface Mount YES
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
