MAX3768CUB-T
RoHS
RoHS compliant
RoHS compliantPackage 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Special Purpose
Description
Limiting Amplifiers 3-5.5V 1.25/2.5Gbps
PDF
/
Buying Options
Total Price: USD $4.2
Unit Price: USD $4.204158
≥1 USD $4.204158
≥10 USD $3.966186
≥100 USD $3.741679
≥500 USD $3.529892
≥1000 USD $3.330085
Inventory: 1188
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Technical
Power Dissipation 1.6W
Nominal Supply Current 39mA
Operating Supply Current 39mA
Min Supply Voltage 3V
Max Supply Voltage 5.5V
Number of Channels 1
Temperature Grade COMMERCIAL
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 10
Base Part Number MAX3768
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Max Power Dissipation 1.6W
Subcategory ATM/SONET/SDH ICs
Applications Optical Networks
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type Limiting Amplifier
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2006
Packaging Tape & Reel (TR)
Physical
Number of Pins 10
Package / Case 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
