MAX3761EEP-T
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Special Purpose
Description
IC LIMITING AMP 20QSOP
PDF
/
Buying Options
Total Price: USD $2.64
Unit Price: USD $2.6353
≥1 USD $2.6353
≥10 USD $2.1622
≥100 USD $2.09475
≥500 USD $2.0273
≥1000 USD $1.95985
Inventory: 1172
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 20-SSOP (0.154, 3.90mm Width)
Surface Mount YES
Technical
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Type Limiting Amplifier
Terminal Finish Tin/Lead (Sn85Pb15)
Applications Optical Networks
HTS Code 8542.39.00.01
Subcategory ATM/SONET/SDH ICs
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.635mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MAX3761
Pin Count 20
JESD-30 Code R-PDSO-G20
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Supplies 5V
Temperature Grade INDUSTRIAL
Supply Current-Max 0.037mA
Dimensions
Height Seated (Max) 1.73mm
Length 8.65mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
