ADA4938-2ACPZ-R2
RoHS
RoHS compliant
RoHS compliantPackage 24-WFQFN Exposed Pad, CSP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Special Purpose
Description
SP Amp DIFF AMP Dual ±5.5V/11V 24-Pin LFCSP EP T/R
PDF
/
Buying Options
Total Price: USD $13.83
Unit Price: USD $13.82535
≥1 USD $13.82535
≥10 USD $11.34395
≥100 USD $10.9896
≥500 USD $10.6343
≥1000 USD $10.27995
Inventory: 3094
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Length 4mm
Height Seated (Max) 1mm
Technical
Negative Supply Voltage-Nom -5V
Input Bias Current 13μA
Interface Standard GENERAL PURPOSE
Dual Supply Voltage 5V
Min Dual Supply Voltage 2.25V
Driver Number of Bits 2
-3db Bandwidth 1 GHz
Max Dual Supply Voltage 5.5V
Input Characteristics DIFFERENTIAL
Power Supply Rejection Ratio (PSRR) 80dB
Differential Output YES
Bandwidth 1 GHz
Input Offset Voltage (Vos) 4mV
Common Mode Rejection Ratio 75 dB
Slew Rate 4700 V/μs
Nominal Supply Current 37mA
Min Supply Voltage -5V
Max Supply Voltage 5V
Temperature Grade INDUSTRIAL
Number of Elements 2
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 24
Base Part Number ADA4938
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Applications Data Acquisition
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 6MOhm
Type ADC Driver
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Discontinued
Pbfree Code no
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Number of Pins 24
Surface Mount YES
Package / Case 24-WFQFN Exposed Pad, CSP
Mounting Type Surface Mount
Contact Plating Tin
