AD8138AARZ-R7
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Special Purpose
Description
Differential Amplifiers Low Distort ADC DVR
PDF
/
Buying Options
Total Price: USD $4.23
Unit Price: USD $4.226065
≥1 USD $4.226065
≥10 USD $3.986857
≥100 USD $3.761178
≥500 USD $3.548286
≥1000 USD $3.347438
Inventory: 1286
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Technical
Min Dual Supply Voltage 1.4V
Max Dual Supply Voltage 5.5V
Power Supply Rejection Ratio (PSRR) 70dB
Voltage Gain 0.028dB
Input Offset Voltage (Vos) 2.5mV
Common Mode Rejection Ratio 70 dB
Power Dissipation 550mW
Min Supply Voltage 2.7V
Max Supply Voltage 11V
Number of Channels 1
Number of Elements 1
Base Part Number AD8138
Applications Data Acquisition
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 6MOhm
Type ADC Driver
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Physical
Supplier Device Package 8-SOIC
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
