TLV376IDBVR
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TLV376 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 2.9mm 0.3pA 7V 5500kHz
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.0736
≥1 USD $1.0736
≥10 USD $0.95744
≥100 USD $0.908512
≥500 USD $0.746152
≥1000 USD $0.697488
≥3000 USD $0.616387
Inventory: 16858
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Surface Mount YES
Number of Pins 5
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Operational Amplifier
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Base Part Number TLV376
Output Type Rail-to-Rail
Number of Circuits 1
Current - Supply 815μA
Slew Rate 2V/μs
Amplifier Type General Purpose
Common Mode Rejection Ratio 88 dB
Current - Input Bias 0.3pA
Voltage - Supply, Single/Dual (±) 2.2V~5.5V ±1.1V~2.75V
Gain Bandwidth Product 5.5MHz
Unity Gain BW-Nom 5500 kHz
Supply Voltage Limit-Max 7V
Voltage - Input Offset 40μV
Current - Output / Channel 30mA
Common-mode Reject Ratio-Min 72 dB
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
RoHS Status ROHS3 Compliant
