TLV271CDBVRG4
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TLV271 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 2.9mm 0.00006muA 5V 3000kHz
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5377
≥1 USD $0.5377
≥10 USD $0.4408
≥100 USD $0.4275
≥500 USD $0.41325
≥1000 USD $0.39995
Inventory: 162593
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Surface Mount YES
Number of Pins 5
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Operational Amplifier
Packing Method TR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Base Part Number TLV271
Pin Count 5
Output Type Rail-to-Rail
Operating Supply Voltage 8V
Number of Elements 1
Operating Supply Current 625μA
Nominal Supply Current 800μA
Power Dissipation 201mW
Output Current 13mA
Slew Rate 2.6V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type CMOS
Common Mode Rejection Ratio 69 dB
Current - Input Bias 1pA
Voltage - Supply, Single/Dual (±) 2.7V~16V ±1.35V~8V
Output Current per Channel 13mA
Input Offset Voltage (Vos) 5mV
Neg Supply Voltage-Nom (Vsup) -5V
Unity Gain BW-Nom 3000 kHz
Voltage Gain 110dB
Average Bias Current-Max (IIB) 0.00006μA
Power Supply Rejection Ratio (PSRR) 70dB
Low-Offset NO
Frequency Compensation YES
Voltage - Input Offset 500μV
Current - Output / Channel 8mA
Low-Bias YES
Micropower NO
Bias Current-Max (IIB) @25C 0.00006μA
Programmable Power NO
Dual Supply Voltage 5V
Nominal Gain Bandwidth Product 3MHz
Max I/O Voltage 5mV
Wideband NO
Input Offset Current-Max (IIO) 0.00006μA
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
