TLV2471AIDR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TLV2471 Tape & Reel (TR) op amp amplifier circuit 4.9mm 0.0003muA 1.6mV 2800kHz
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.10105
≥100 USD $1.06685
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 1349
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Input Offset Current-Max (IIO) 0.00005μA
Max I/O Voltage 1.6mV
Programmable Power NO
Bias Current-Max (IIB) @25C 0.00005μA
Micropower NO
Low-Bias YES
Voltage - Input Offset 250μV
Supply Voltage Limit-Max 7V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.0003μA
Voltage Gain 120dB
Unity Gain BW-Nom 2800 kHz
Bandwidth 2.8MHz
Input Offset Voltage (Vos) 1.6mV
Output Current per Channel 35mA
Voltage - Supply, Single/Dual (±) 2.7V~6V ±1.35V~3V
Current - Input Bias 2.5pA
Common Mode Rejection Ratio 61 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 1.5V/μs
Output Current 35mA
Power Dissipation 710mW
Nominal Supply Current 900μA
Operating Supply Current 600μA
Number of Elements 1
Operating Supply Voltage 3V
Output Type Rail-to-Rail
Pin Count 8
Base Part Number TLV2471
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 710mW
Packing Method TR
Subcategory Operational Amplifier
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
