TLV2465CNE4
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
RoHS Compliant EAR99 PDIP VOLTAGE-FEEDBACK op amp buffer circuit 19.305mm 0.025muA 500muV 5200kHz
PDF
/
Inventory: 6178
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 19.305mm
Height Seated (Max) 5.08mm
Technical
Power NO
Programmable Power NO
Min Dual Supply Voltage 1.35V
Micropower NO
Low-Bias NO
Max Dual Supply Voltage 3V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.025μA
Voltage Gain 109dB
Unity Gain BW-Nom 5200 kHz
Gain Bandwidth Product 6.4MHz
Bandwidth 5.2MHz
Input Offset Voltage (Vos) 500μV
Output Current per Channel 80mA
Current - Input Bias 1.3nA
Common Mode Rejection Ratio 71 dB
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Slew Rate 1.6 V/μs
Current - Output 80mA
Nominal Supply Current 2.6mA
Operating Supply Current 550μA
Min Supply Voltage 2.7V
Max Supply Voltage 6V
Number of Channels 4
Temperature Grade COMMERCIAL
Operating Supply Voltage 3V
Pin Count 16
Supply Voltage 3V
Number of Functions 4
Terminal Position DUAL
Technology CMOS
Packing Method TUBE
Subcategory Operational Amplifier
Min Operating Temperature 0°C
Max Operating Temperature 70°C
ECCN Code EAR99
Number of Terminations 16
Pbfree Code yes
Physical
Number of Pins 16
Package / Case PDIP
Mount Through Hole
