TLV2262QD
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Contains Lead Not Qualified GULL WING Rail-to-Rail General Purpose Amplifier 70dB 0.55V/mus -40C~125C 670kHz
PDF
/
Buying Options
Total Price: USD $1.29
Unit Price: USD $1.287748
≥1 USD $1.287748
≥10 USD $1.214856
≥100 USD $1.146098
≥500 USD $1.081218
≥1000 USD $1.02002
Inventory: 1083
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Bias Current-Max (IIB) @25C 0.00006μA
Micropower YES
Low-Bias YES
Supply Voltage Limit-Max 16V
Frequency Compensation YES
Low-Offset NO
Voltage Gain 114.81dB
Unity Gain BW-Nom 670 kHz
Gain Bandwidth Product 710kHz
Bandwidth 670 kHz
Input Offset Voltage (Vos) 300μV
Output Current per Channel 50mA
Voltage - Supply, Single/Dual (±) 2.7V~8V ±1.35V~4V
Current - Input Bias 1pA
Common Mode Rejection Ratio 70 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.55V/μs
Output Current 50mA
Nominal Supply Current 500μA
Operating Supply Current 400μA
Number of Circuits 2
Power Supplies 3/5V
Operating Supply Voltage 4V
Output Type Rail-to-Rail
Qualification Status Not Qualified
Pin Count 8
Base Part Number TLV2262
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 3V
Number of Functions 2
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Operational Amplifier
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series LinCMOS?
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
