TLE2161CDG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Lead Free GULL WING OPERATIONAL AMPLIFIER BIPOLAR OPERATIONAL AMPLIFIER Amplifier 725mW 65dB 10V/mus 70C
PDF
/
Buying Options
Total Price: USD $1.01
Unit Price: USD $1.005681
≥1 USD $1.005681
≥200 USD $0.389931
≥500 USD $0.375489
≥1000 USD $0.368925
Inventory: 9595
Minimum: 1
-
+
Technical Details
Physical
Package / Case SOIC
Surface Mount YES
Number of Pins 8
Technical
Packaging Rail/Tube
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Subcategory Operational Amplifier
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Pin Count 8
Operating Supply Voltage 18V
Number of Elements 1
Temperature Grade COMMERCIAL
Operating Supply Current 290μA
Nominal Supply Current 35μA
Power Dissipation 725mW
Slew Rate 10 V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type OPERATIONAL AMPLIFIER
Common Mode Rejection Ratio 65 dB
Current - Input Bias 2nA
Output Current per Channel 80mA
Input Offset Voltage (Vos) 3.1mV
Bandwidth 5.8MHz
Gain Bandwidth Product 5.8MHz
Neg Supply Voltage-Nom (Vsup) -5V
Unity Gain BW-Nom 5800 kHz
Voltage Gain 98.06dB
Average Bias Current-Max (IIB) 0.002μA
Low-Offset NO
Frequency Compensation YES AVCL>=5
Max Dual Supply Voltage 18V
Low-Bias YES
Micropower YES
Min Dual Supply Voltage 3.5V
Dual Supply Voltage 9V
Nominal Gain Bandwidth Product 5.8MHz
Max I/O Voltage 3.1mV
Dimensions
Height 1.58mm
Length 4.9mm
Width 3.91mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
