TLE2071CP
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TLE2071 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 9.81mm 0.005muA 9V 10000kHz
PDF
/
Buying Options
Total Price: USD $2.55
Unit Price: USD $2.552
≥1 USD $2.552
≥10 USD $2.29152
≥100 USD $2.161984
≥500 USD $1.842016
≥1000 USD $1.729587
≥3000 USD $1.513406
Inventory: 527
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 3.9mm
Width 6.35mm
Length 9.81mm
Height 5.08mm
Technical
Power NO
Max I/O Voltage 4mV
Nominal Gain Bandwidth Product 9.4MHz
Dual Supply Voltage 9V
Programmable Power NO
Micropower NO
Low-Bias YES
Voltage - Input Offset 490??V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.005??A
Voltage Gain 106dB
Unity Gain BW-Nom 10000 kHz
Neg Supply Voltage-Nom (Vsup) -5V
Gain Bandwidth Product 10MHz
Bandwidth 9.4MHz
Input Offset Voltage (Vos) 4mV
Output Current per Channel 48mA
Voltage - Supply, Single/Dual (?±) 4.5V~38V ?±2.25V~19V
Current - Input Bias 20pA
Common Mode Rejection Ratio 70 dB
Amplifier Type J-FET
Architecture VOLTAGE-FEEDBACK
Slew Rate 45V/??s
Max Supply Current 2.2mA
Output Current 48mA
Nominal Supply Current 2.2mA
Operating Supply Current 1.7mA
Number of Channels 1
Operating Supply Voltage 19V
Pin Count 8
Base Part Number TLE2071
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Technology BIFET
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Excalibura??
Packaging Tube
Operating Temperature 0?°C~70?°C
Physical
Number of Pins 8
Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
