TLE2071ACDRG4
RoHS
/
Package D
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
IC OPAMP JFET 10MHZ SGL LN 8SOIC
PDF
/
Buying Options
Total Price: USD $1.69
Unit Price: USD $1.69195
≥1 USD $1.69195
≥10 USD $1.38795
≥100 USD $1.3452
≥500 USD $1.3015
≥1000 USD $1.2578
Inventory: 1152
Minimum: 1
-
+
Technical Details
Physical
Package / Case D
Surface Mount YES
Number of Pins 8
Technical
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
ECCN Code EAR99
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Subcategory Operational Amplifier
Technology BIFET
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Pin Count 8
Operating Supply Voltage 19V
Temperature Grade COMMERCIAL
Number of Channels 1
Operating Supply Current 1.7mA
Nominal Supply Current 2.2mA
Current - Output 48mA
Slew Rate 35 V/μs
Amplifier Type OPERATIONAL AMPLIFIER
Common Mode Rejection Ratio 70 dB
Current - Input Bias 175pA
Output Current per Channel 48mA
Input Offset Voltage (Vos) 470μV
Bandwidth 9.4MHz
Gain Bandwidth Product 9.4MHz
Neg Supply Voltage-Nom (Vsup) -5V
Unity Gain BW-Nom 9400 kHz
Voltage Gain 106dB
Average Bias Current-Max (IIB) 0.005μA
Low-Offset NO
Frequency Compensation YES
Max Dual Supply Voltage 19V
Low-Bias YES
Min Dual Supply Voltage 2.25V
Nominal Gain Bandwidth Product 9.4MHz
Max I/O Voltage 2mV
Dimensions
Length 4.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
