TLC27L4ACNSR

Texas Instruments
RoHS
/
Package /
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description Not Qualified GULL WING OPERATIONAL AMPLIFIER CMOS op amp amplifier circuit 94dB 0.03V/us 70C 85kHz
PDF
/
Inventory: 3858
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Width 5.3mm
Length 10.2mm
Height Seated (Max) 2mm

Technical

Input Offset Voltage-Max 6500μV
Supply Voltage Limit-Max 18V
Average Bias Current-Max (IIB) 0.0006μA
Unity Gain BW-Nom 85 kHz
Common Mode Rejection Ratio 94 dB
Amplifier Type OPERATIONAL AMPLIFIER
Slew Rate 0.03 V/us
Temperature Grade COMMERCIAL
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G14
Pin Count 14
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 220; 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Operational Amplifier
HTS Code 8542.33.00.01
Terminal Finish NICKEL PALLADIUM GOLD
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 2
JESD-609 Code e4

Physical

Surface Mount YES
