TLC27L2BCDG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
RoHS Compliant EAR99 Nickel/Palladium/Gold (Ni/Pd/Au) Rail/Tube op amp buffer circuit 4.9mm 0.0006muA 2mV 100kHz
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.224625
≥1 USD $3.224625
≥10 USD $3.042099
≥100 USD $2.869909
≥500 USD $2.707465
≥1000 USD $2.554203
Inventory: 990
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.91mm
Length 4.9mm
Height 1.58mm
Technical
Max I/O Voltage 2mV
Nominal Gain Bandwidth Product 85 kHz
Programmable Power NO
Bias Current-Max (IIB) @25C 0.00006μA
Micropower YES
Low-Bias YES
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.0006μA
Voltage Gain 116.9dB
Unity Gain BW-Nom 100 kHz
Gain Bandwidth Product 85 kHz
Bandwidth 85 kHz
Input Offset Voltage (Vos) 2mV
Output Current per Channel 30mA
Current - Input Bias 60pA
Common Mode Rejection Ratio 65 dB
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.03 V/μs
Power Dissipation 725mW
Nominal Supply Current 46μA
Operating Supply Current 29μA
Min Supply Voltage 3V
Max Supply Voltage 16V
Temperature Grade COMMERCIAL
Number of Elements 2
Pin Count 8
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Operational Amplifier
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Packaging Rail/Tube
Physical
Number of Pins 8
Surface Mount YES
Package / Case SOIC
