TLC277MFKB
RoHS
/
Package /
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Contains Lead Not Qualified NO LEAD OPERATIONAL AMPLIFIER op amp buffer circuit 80dB 2.9V/us -55C 320kHz
PDF
/
Inventory: 8921
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount YES
Number of Pins 8
Technical
Pbfree Code no
Number of Terminations 20
ECCN Code EAR99
Subcategory Operational Amplifier
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 2
Supply Voltage 5V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 20
Qualification Status Not Qualified
Operating Temperature (Min) -55°C
Power Supplies 4/16V
Temperature Grade MILITARY
Number of Channels 2
Supply Current-Max 5mA
Slew Rate 2.9 V/us
Architecture VOLTAGE-FEEDBACK
Amplifier Type OPERATIONAL AMPLIFIER
Common Mode Rejection Ratio 80 dB
Gain Bandwidth Product 320 kHz
Unity Gain BW-Nom 1700 kHz
Average Bias Current-Max (IIB) 0.00006μA
Low-Offset NO
Frequency Compensation YES
Low-Bias YES
Micropower NO
Bias Current-Max (IIB) @25C 0.00006μA
Programmable Power NO
Input Offset Voltage-Max 3750μV
Wideband NO
Power NO
Voltage Gain-Min 3500
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
